| Min. Order: | 1 Piece/Pieces |
|---|---|
| Trade Term: | FOB,CFR,DDP,DAP,FCA,EXW |
| Payment Terms: | L/C, D/P, T/T |
| Place of Origin: | Zhejiang, China (Mainland) |
| Means of Transport: | Ocean, express, Air, Land |
| Production Capacity: | 100pcs per month |
| Packing: | plywood |
| Delivery Date: | 15-25days | Processing Types: | Metal |
|---|---|---|---|
| Processing: | Grinding Machine | Automatic Grade: | Others |
| Precision: | High Precision | Workpiece and Weight: | Large Machine Tool |
| Controlling Mode: | Others | Usage: | General |
| Brand Name: | SYF MAG | waterproof: | full submersible |
| clamping workpieces: | comprehensive clamping of workpieces of various sizes. | holding force: | 120 N/cm² |
| Pole pitch:: | 3+5+0.5+5+0.5+5 mm |
Application:
Suitable for comprehensive clamping of workpieces of various sizes.
Features:
Pole pitch: 3+5+0.5+5+0.5+5 mm
Uniform magnetic force up to 140 N/cm²
Electro-permanent magnetic technology, no thermal deformation
With demagnetization function to remove residual magnetism in workpieces
Waterproof structure
Rugged one-piece base minimizes mechanical deformation.
Category: electro permanent magnetic chuck
